Straightpoint Arborist Load Cell Impact Block

The safest choice for the professional arborist, Straightpoint's load cell impact block has been designed to deliver best-in-class performance, alignment, and resistance, as well as aesthetic appeal, the latter courtesy of its neatly curved profile, expertly combining looks, strength and durability, ensuring a rope-friendly surface for the duration of its shelf-life.

Undergoing rigorous dynamic and static validation testing during its development, this impact block load cell from the SP range is super functional with a truly impressive strength-to-weight ratio.

Teamed up with other wireless dynamic load monitoring equipment and strain gauge technology from SP, real-time data can be recorded by either a handheld controller or via the INSIGHT software available on any tablet or laptop.

• The safest choice for the working arborist
• Best performance in alignment, resistance and appeal
• Strong and durable
• Thorough dynamic and static validation testing
• Impressive strength to weight ratio

Part Number	WIB6T
Capacity	60kN
Resolution	0.1kN
Weight	6kg
	13lbs
Safety factor	5:1
Battery Type	4x AA Alkaline
Battery Life	1200Hrs continuous
Operating Temp	-10 to 50 deg C
	14 to 122˚F
Accuracy	±0.1% full scale
Frequency	2.4GHz
Range	1000 metres (100m if Bluetooth)
	3280 feet (328ft if Bluetooth)
Data Rate	50Hz upto 200Hz
Protection	IP67
Max Rope Ø	20
	0.75
Dimension A	348
	13.70"
Dimension B	89
	3.5"
Dimension C	131
	5.16"
Dimension D	242
	9.53"
Dimension ØE	27
	1.06"
